Brother DCP-L5652DN Service Manual

4-5
Confidential
1.2 Adjusting Touch Panel (Function Code: 61)
Adjust the touch panel as described in “1.3.19 Adjust touch panel (function code: 61)” in
Chapter 5
.
1.3 Initializing the EEPROM of the Main PCB ASSY
(Function Code: 01)
Initialize the EEPROM of the main PCB ASSY as described in “1.3.1 Initialize EEPROM
parameters (function code: 01, 91)” in Chapter 5
.
1.4 Configure for Country/Region and Model
(Function Code: 74)
Perform settings for a country/region as described in “1.3.24 Configure for country/region
and model (function code: 74)” in Chapter 5
.
1.5 Activating Memory Writing
<Operating Procedure>
(1) Check that the machine is in the initial state of maintenance mode.
(2) Connect the computer to the machine with the USB cable.
(3) Check that the "Brother Maintenance USB Printer" is set as a default printer. If not, set it
as a default printer.
(4) Double-click the "MemoryAccessTool.exe" file. The following window appears.
(5) Enter the [Y]. Memory writing is activated.
Note:
• Setting serial number and entering adjusted value of the laser unit are not operable
before activating the memory writing.
• Even the memory writing has been activated by following the procedure, you cannot
confirm it on the machine. Therefore, if setting serial number and entering adjusted
value of the laser unit are inoperable, perform the procedure again.

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
