Brother DCP-L5652DN Service Manual

2-88
Confidential
4.2.8 Paper is curled
4.2.9 Duplex printing is not possible
<User Check>
• Check that the paper specified in driver settings is matched to the paper set.
• Select "Reduce Paper Curl" in the driver.
• Check that the paper is set in each paper tray correctly.
• Open the back cover and try printing with straight paper ejection mode.
Step Cause Remedy
1 Fuser unit failure Replace the fuser unit.
2 Main PCB failure Replace the main PCB ASSY.
<User Check>
• Close the back cover completely.
• Set the duplex tray correctly.
• Set the driver setting to duplex printing.
• Use A4 or Letter paper specified by the manufacturer.
Step Cause Remedy
1 Back cover failure Replace the back cover.
2 Eject motor failure Replace the eject motor.
3
Back cover/duplex tray sensor
failure
Replace the back cover/duplex tray sensor.
4 Duplex tray failure Replace the duplex tray.
5 Main PCB failure Replace the main PCB ASSY.
6
Damaged gears in the ejecting
system
Replace the main frame L ASSY.

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
