Brother DCP-L5652DN Service Manual

2-74
Confidential
 Error code A400
The ADF cover sensor detected that the ADF cover was open.
 Error code A500
When scanning the fax, white or black correction data for the first side CIS unit was not within
the correct range (first time).
Error code A600
When scanning the fax, white or black correction data for the first side CIS unit was not within
the correct range (second time).
<User Check>
• Close the ADF cover correctly.
Step Cause Remedy
1
A part to push the ADF cover
sensor in the ADF cover is
broken.
Replace the ADF cover ASSY.
2 ADF cover sensor failure Replace the ADF unit.
3 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Incorrect correction data for first
side CIS unit
Execute "Acquire white level data (function
code: 55)".
2
Dirt on the white tape on the
second side document hold
Clean the white tape on the second side
document hold.
3 First side CIS unit failure Replace the first side CIS unit.
4 White tape failure Replace the document scanner unit.
5 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
