Brother DCP-L5652DN Service Manual

2-81
Confidential
 Error code EC00
A USB device not within the specification is connected to the USB terminal, resulting in over
current.
 Error code ED00
Failed to authenticate the firmware for the self test.
Error code EE00
Failed to authenticate the NVRAM for the self test.
 Error code F900
The spec code was not entered correctly.
<User Check>
• Disconnect the USB device from the USB flash memory port and turn the machine OFF.
Turn the machine ON again after a while.
• Replace the USB device with a different one.
Step Cause Remedy
1 USB host PCB failure Replace the USB host PCB ASSY.
2 Main PCB failure Replace the main PCB ASSY.
<User Check>
• Turn the power switch OFF and then ON again.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
The power was turned OFF
while function code 74 was
running.
Reenter the spec code.
2 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
