Brother DCP-L5652DN Service Manual

2-92
Confidential
 Paper jams in MP tray
<User Check>
• Check that the paper is set in the MP tray correctly.
• Flip over the paper in the MP tray or rotate the paper 180°.
• Adjust the paper guide according to the paper size.
• Check that the thickness of the paper is 60 to 200 g/m
2
.
• Flip through the paper and reset it in the MP tray.
Step Cause Remedy
1
Foreign object around the MP
tray
Remove the foreign object.
2
Connection failure of the
registration front/rear sensor
harness
Reconnect the registration front/rear sensor
harness.
3
Registration front actuator
coming off
Reattach the registration front actuator.
4
Connection failure of the
registration clutch harness
Reconnect the registration clutch harness.
5
Connection failure of the HVPS
flat cable
Reconnect the HVPS flat cable.
6
Connection failure of the relay
front harness
Reconnect the relay front harness.
7
Registration front sensor failure Replace the registration front/rear sensor PCB
ASSY.
8 Registration clutch failure Replace the registration clutch.
9 Paper feed motor failure Replace the paper feed motor.
10 Relay front PCB failure Replace the relay front PCB ASSY.
11
High-voltage power supply PCB
failure
Replace the high-voltage power supply PCB
ASSY.
12
Damaged gears in the paper
feeding system
Replace the main frame L ASSY.
13 Damaged fuser unit Replace the fuser unit.
14 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
