Brother DCP-L5652DN Service Manual

1-3
Confidential
Model MFC-L5755DW
MFC-L5800DW
MFC-L5802DW
MFC-L5850DW
MFC-L5900DW
MFC-L5902DW
MFC-L6700DW
MFC-L6702DW
MFC-L6750DW
MFC-L6800DW
MFC-L6900DW
MFC-L6902DW
Wired/
Wireless
LAN
Wired/Wireless
Duplex
Printing

Auto
Duplex
Copy

N/A 
Duplex
Scan

N/A 
Scanning
Method
Dual CIS CIS Dual CIS
LCD Type
3.7" TFT ColorLCD
(9.3 cm / 93.4 mm)
4.85" TFT ColorLCD
(12.3 cm / 123.2 mm)
FAX 
FB A4/LTR LGL
USB Host
(front)

USB Host
(rear)
N/A 
NFC
N/A 
PCL/PS 
Paper
Input/
Standard
Tray
250 sheets 520 sheets
Lower Tray
(Option)
250 sheets (LT-5500) or 520 sheets (LT-6500) x 2 pcs
(Max. 1,040 sheets)
250 sheets
(LT-5500 for
the U.S.A./
LT-5505 for
Europe) or
520 sheets
(LT-6500 for
the U.S.A./
LT-6505 for
Europe)
x 2 pcs
(Max. 1,040
sheets)
250 sheets
(LT-5505) or
520 sheets
(LT-6505)
x 2 pcs
(Max. 1,040
sheets)
Tower Tr a y
(Option)
N/A 
Specifications are subject to change without notice.

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
