Brother DCP-L5652DN Service Manual

3-54
Confidential
■ For A4
Fig. 3-46
■ For LGL, Models without USB host on the rear side only
Fig. 3-47
■ For LGL, Models with USB host on the rear side only
Fig. 3-48
Assembling Note:
• Fold the second side CIS flat cable at the positions shown in the figure below.
530±2
113±1
135±1
139±1
422±2
1±1
1±1
279±1
304±1
331±1
358±1
408±1
78±1
69.4±1
45°
45°45°
45°
Mountain fold
Valley fold
Reinforcing
plate
Fold at edge of
reinforcing plate
Reinforcing
plate
Double-sided
tape (Attach it
to the flat
cable holder.)
Guide sponge
(Attach it after
wiring)
Double-sided
tape
(Attach it to
the document
cover.)
Reinforcing tape
CIS side
Main PCB side
408±1
403±1
390±1
345±1
318±1
291±1
530±2
113±1
135±1
139±1
422±2
1±1
1±1
65±1
266±1
63±1
45°
45° 45°
45°
45°
45°
45°
45°
Guide sponge
(Attach it after wiring.)
Fold at edge of
reinforcing plate
Double-sided
tape
(Attach it to
the document
cover.)
Double-sided
tape (Attach it
to the flat
cable holder.)
Reinforcing tape
Main PCB side
CIS side
Reinforcing
plate
Reinforcing
plate
Valley fold
Mountain fold
478±2
113±1
135±1
139±1
370±2
356±1
1±1
1±1
65±1
63±1
45° 45°
CIS side
Main PCB side
Reinforcing plate
Fold at edge of
reinforcing plate
Reinforcing
plate
Guide sponge
(Attach it after wiring.)
Double-sided tape
(Attach it to the flat
cable holder.)
Reinforcing tape
Double-sided
tape
(Attach it to
the document
cover.)
Mountain fold
Valley fold

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
