Brother DCP-L5652DN Service Manual

5-55
Confidential
RE_JAM:00000000 Paper jams that have occurred at the ejecting section or back
cover
DX_JAM:00000000 Paper jams that have occurred in the duplex tray
POWER:00000375 Total power distribution time (unit: hour)
PWRCNT:00000001 The number of times that the power is turned ON
KTN_CH:0000
The number of times that the toner cartridge has been replaced
*4
DRUM_CH:0000
The number of times that the drum unit has been replaced
*4
FUSR_CH:0000
The number of times that the fuser unit has been replaced
*4
LASR_CH:0000
The number of times that the laser unit has been replaced
*4
PFMP_CH:000 The number of times that the PF kit MP has been replaced
PFK1_CH:000 The number of times that the PF kit 1 has been replaced
PFK2_CH:000 The number of times that the PF kit 2 has been replaced
PFK3_CH:000 The number of times that the PF kit 3 has been replaced
PFK4_CH:000 The number of times that the PF kit 4 has been replaced
PFK5_CH:000 The number of times that the PF kit 5 has been replaced
KTN_PG1:00000000 Pages printed with the current toner cartridge
KTN_PG2:00000000 Pages printed with the previous toner cartridge
WTNR_PG:00000000
The number of pages printed from the waste toner box
SCN_PG:00000000
The number of scanned pages (except Fax and Copy)
ADSX_PG:00000000
ADF single-side scanned pages (duplex scanning models only)
ADDX_PG:00000000
ADF double-side scanned pages (duplex scanning models only)
ADTL_PG:00000000
Total pages of ADSX_PG and ADDX_PG
FB_PG:000000
Total FB scanned pages
ADSX_JAM:000000
Document jams that have occurred on ADF single-side scanning
(duplex scanning models only)
ADDX_JAM:000000
Document jams that have occurred on ADF duplex scanning
(duplex scanning models only)
FXTX_PG The number of faxed pages
COMERR#:00000000
Communication error log (past three errors)
*5
(models with fax only)
KDEV_BIAS:400V Black developing bias voltage value
ENGERR##:000000
Engine error log (last ten errors)
*6
HODN_ER:0000 The number of discharge errors occurred
FUSR_ER:0000 The number of fuser unit errors occurred
MTLK_ER:0000
The number of polygon motor lock errors occurred in the laser scanner
DEVSTATUS__##:00
Log for design analysis
*7
LCD Description

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
