Brother DCP-L5652DN Service Manual

2-9
Confidential
Part name Operation
MP separation roller,
MP separation pad
Separates the paper fed from the MP tray into single sheets in
the MP separation roller.
MP paper empty actuator
(MP paper empty sensor)
Detects the paper in the MP tray.
Detects paper jams in the MP tray.
Eject stack actuator
(Eject stack sensor)
Detects the full of a machine output tray.
(Models with USB host on the rear side only.)
Document pick-up roller Feeds document from the document tray.
Document separate roller,
ADF separation pad
Separates the document fed from the document tray into single
sheets.
Document detection actuator
(Document detection
sensor)
Detects whether a document is set in the ADF.
Document scanning position
actuator
(Document scanning
position sensor)
Detects the document scanning start position.
Detects a document jam in the ADF.
Document eject roller Feeds the document to the output tray.
ADF cover sensor Detects open / closed ADF cover.

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
