Brother DCP-L5652DN Service Manual

2-17
Confidential
Error
codes
Description
Refer
to:
Error
codes
Description
Refer
to:
7602
When printing from the paper tray 4,
the registration front sensor or the T2/
T3/T4TT jam sensor does not detect
paper pass within the specified time
after the T4(LT or TT) paper feed
sensor detected paper pass.
2-59
7C00 ―
7701
When printing from the paper tray 5,
the T5TT paper feed sensor does not
detect paper pass within the specified
time while the T5TT paper empty
sensor detects some paper set.
2-60 7D00 ―
7702
When printing from the paper tray 5,
the registration front sensor or the T2/
T3/T4/T5TT jam sensor does not
detect paper pass within the specified
time after the T5TT paper feed sensor
detected paper pass.
2-61
7E00 ―
7800
The registration front sensor does not
detect paper pass within the specified
time after the first side was printed in
duplex printing mode.
2-62
7F00 ―
7801 ― 8000 ―
7802 ― 8100 ―
7803 ― 8401 ―
7804 ― 8402 ―
7805 ― 8403 ―
7900 ― 8501
When printing from paper tray 1 to 5,
the T1 paper feed sensor detected
open paper tray 1 (before registering
printing data to engine).
2-63
7A01 ― 8502
When printing from paper tray 2 to 5,
the T2(LT or TT) paper feed sensor
detected open paper tray 2 (before
registering printing data to engine).
2-63
7A02 ― 8503
When printing from paper tray 3 to 5,
the T3(LT or TT) paper feed sensor
detected open paper tray 3 (before
registering printing data to engine).
2-63
7B01 ― 8504
When printing from paper tray 4 to 5,
the T4(LT or TT) paper feed sensor
detected open paper tray 4 (before
registering printing data to engine).
2-63
7B02 ― 8505
When printing from paper tray 1 to 5,
the T1 paper feed sensor detected
open paper tray 1 (after registering
printing data to engine).
2-64
7B03 ― 8506
When printing from paper tray 2 to 5,
the T2(LT or TT) paper feed sensor
detected open paper tray 2 (after
registering printing data to engine).
2-64
7B04 ― 8507
When printing from paper tray 3 to 5,
the T3(LT or TT) paper feed sensor
detected open paper tray 3 (after
registering printing data to engine).
2-64
7B05 ― 8508
When printing from paper tray 4 to 5,
the T4(LT or TT) paper feed sensor
detected open paper tray 4 (after
registering printing data to engine).
2-64

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
