Brother DCP-L5652DN Service Manual

2-42
Confidential
 Error code 0900
Detected irregular power supply for more than 100 times.
 Error code 0A02
Detected a main fan failure.
 Error code 0B01
An error occurred in the high-voltage power supply PCB ASSY while operating.
Error code 0B02
An error occurred in the high-voltage power supply PCB ASSY when the machine was in the
ready state.
<User Check>
• Turn OFF the power switch. After several seconds, turn ON the power again and check
that this error is reset.
Step Cause Remedy
1
Low-voltage power supply PCB
failure
Replace the low-voltage power supply PCB
ASSY. Refer to “1.3.31 Reset counters for
consumable parts (function code: 88)” in
Chapter 5 to reset the irregular power supply
detection counter after the replacement.
2 Main PCB failure Replace the main PCB ASSY.
Note:
• The irregular power supply detection error of the low-voltage power supply PCB (error
code: 0900) occurs when there is a large distortion in the power supply voltage
supplied to the machine. In this case, if the same power supply is used, the same error
may occur even when the low-voltage power supply PCB ASSY is replaced. Ask the
user to review the installation environment.
• Do not reset the power supply PCB counter before replacing it with a new one. It may
cause fire.
Step Cause Remedy
1
Connection failure of the main fan
harness
Reconnect the main fan harness.
2
Connection failure of the toner
amount detection sensor PCB
harness (light emission)
Reconnect the toner amount detection sensor
PCB harness (light emission).
3 Main fan failure Replace the main fan.
4
Low-voltage power supply PCB
failure
Replace the low-voltage power supply PCB
ASSY.
5
Toner amount detection sensor
PCB (light emission) failure
Replace the toner amount detection sensor
PCB ASSY (light emission).
6 Main PCB failure Replace the main PCB ASSY.
<User Check>
• Replace the drum unit. (corona wire breakage)
Step Cause Remedy
1
Connection failure of the HVPS
flat cable
Reconnect the HVPS flat cable.
2
High-voltage power supply PCB failure Replace the high-voltage power supply PCB ASSY.
3 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
