Brother MFC-7365DN Service Manual

2-55
Confidential
■ Error code 9D to 9F, A0
These errors do not usually occur in the normal use. The conceivable causes are noise around
the installation site, fluctuation of the power supply voltage, and failures in the software.
Error, which cannot be specified, occurs.
■ Error code A1
The front cover is open.
---
<User Check>
• Turn OFF the power switch, and turn it ON again after a while.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
Cover is Open
Close the Front Cover.
<User Check>
• Check if the front cover is closed correctly.
Step Cause Remedy
1
Harness connection failure of high
voltage power supply PCB ASSY
(Front cover sensor is mounted in
high voltage power supply PCB
ASSY.)
Check the harness connection of the high
voltage power supply PCB ASSY, and
reconnect it.
2
Part pressing the front cover
sensor is broken, which is
provided at inside of front cover
Replace the front cover ASSY.
3
Front cover sensor failure Check the front cover sensor performance
following the procedure described in
"Function code 32". If any problem occurs,
replace the high voltage power supply PCB
ASSY.
4 Main PCB failure Replace the main PCB ASSY.

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
