Brother MFC-J2320 Service Manual

3-48
Confidential
Assembling Note: Assemble new Second side CIS flat cable as shown below.
Fig. 3-38
Folding instructions
Top: White side
Bottom: UL symbol print side
(Unit: mm)
647
178 124
9.5
34 158
9.5
34
70
13453
204
211 36274
45° 45°
45°
45°
Insulating tape
(White in color)
53
Fold
position "A"*
To CIS unit To main body
Mountain fold
Valley fold
* : At fold position "A", bend the cable
along the end of the reinforcement
plate.
Double-sided tape attachment position
81
64
53
30
158
352
70
91
34
UL symbol print side
Double-sided
tape
To main body
To
CIS unit
Double-sided tape
(Bottom when viewed
from this side (White
side ))

Brother MFC-J2320 Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi
Max Print Resolution	6000 x 1200 dpi
Max Print Size	A3
Scanner Type	Flatbed with ADF
Max Scan Resolution	1200 x 2400 dpi
Copy Speed (Black)	12 cpm
Copy Speed (Color)	9 cpm
Paper Tray Capacity	250 sheets
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Display	2.7" LCD touchscreen
Paper Handling	A3, A4
