Confidential
2-59
4.2.2 Paper is not fed from manual feed slot
User Check
- Check that recording paper is loaded correctly in the manual feed slot.
- Check thickness of recording paper is within tolerance of each type.
- Check only a single recording paper enters.
4.2.3 Paper is not fed from MP tray
User Check
- Check that recording paper is loaded correctly in the MP tray.
- Check thickness of recording paper is within tolerance of each type.
- Check that setting of tray selection is not fix to the paper tray.
- Check that the paper smaller than the specified size is not loaded.
- Adjust the paper guide to match the recording paper size.
- Try reversing the recording paper in the MP tray, or rotating direction of the paper for
180 degrees.
- Check that the number of recording paper loaded in the MP tray is within specified
volume.
- Clean the MP pull-in roller.
Step Cause Solution
1 Paper feed motor harness
connection failure
Reconnect the paper feed motor harness.
2
Registration actuator out of place
Set the registration actuator into place.
3 Registration sensor defective Replace the registration sensor PCB ASSY.
4 Paper feed motor defective Replace the paper feed motor.
5 Main PCB defective Replace the main PCB ASSY.
Step Cause Solution
1 Paper feed motor harness
connection failure
Reconnect the paper feed motor harness.
2 MP paper detection sensor
harness connection failure
Reconnect the MP paper detection sensor
harness.
3 Sensor relay PCB harness
connection failure
Reconnect the sensor relay PCB harness.
4 MP paper detection actuator
out of place
Set the MP paper detection actuator into place.
5 MP paper detection sensor
defective
Replace the MP paper detection sensor PCB
ASSY.
6 Sensor relay PCB defective Replace the sensor relay PCB.
7 Paper feed motor defective Replace the paper feed motor.
8 MP drive gear broken
MP pull-in roller worn out
Replace the MP unit.
9 Main PCB defective Replace the main PCB ASSY.
To Next Page
