Brother MFC-J2320 Service Manual

1-4
Confidential
1.7 Others
2FAX
Model MFC-J2320 MFC-J2720 MFC-J5320DW
MFC-J5520DW/
J5620DW/
J5625DW
MFC-J5720DW/
J5920DW
Operating Environment
Temperature
(Best Print Quality)
10-35 (20-33) degrees centigrade
Operating Environment
Humidity
(Best Print Quality)
20-80 (20-80) %
Power
Consumption
(Operating/
Standby/Sleep
mode/Off)
U.S.A
N/A 31 w/5.0 w/1.7 w/0.04 w
Europe 32 w/5.5 w/1.8 w/0.04 w
Asia/Oceania 32 w/5.5 w/1.8 w/0.04 w
China 32 w/5.5 w/1.8 w/0.04 w
N/A
Machine Noise (Operating)
50 dBA
Machine Dimensions
W490 x D290 x
H240 mm
W490 x D345 x
H308 mm
W490 x D290 x
H240 mm
W490 x D345 x
H240 mm
W490 x D345 x
H308 mm
Machine Weight 10.8/23.8 (kg/lbs) 14.5/31.9 (kg/lbs) 10.8/23.8 (kg/lbs)
For US
11.6/25.5 (kg/lbs)
Except for US
11.7/25.7 (kg/lbs)
For US
14.4/31.7 (kg/lbs)
Except for US
14.5/31.9 (kg/lbs)
Model MFC-J2320 MFC-J2720 MFC-J5320DW
MFC-J5520DW/
J5620DW/
J5625DW
MFC-J5720DW/
J5920DW
Modem Speed (bps) 14,400(FAX) 33,600 (FAX) 14,400(FAX) 33,600 (FAX)
Transmission Speed
Approx.7 sec
(ITU-T Test Chart
#1,MMR)
Approx.3 sec
(ITU-T Test Chart
#1,MMR)
Approx.7 sec
(ITU-T Test Chart
#1,MMR)
Approx.3 sec
(ITU-T Test Chart #1,MMR)
ITU-T Group G3 Super G3 G3 Super G3
COLOR
FAX
Document
(Send/Receive)
Yes/Yes (ITU-T color FAX)
Memory
(Send/Receive)
No/No (ITU-T color FAX)

Brother MFC-J2320 Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi
Max Print Resolution	6000 x 1200 dpi
Max Print Size	A3
Scanner Type	Flatbed with ADF
Max Scan Resolution	1200 x 2400 dpi
Copy Speed (Black)	12 cpm
Copy Speed (Color)	9 cpm
Paper Tray Capacity	250 sheets
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Display	2.7" LCD touchscreen
Paper Handling	A3, A4
