Page #89 background imageLoading...
Page #89 background image
Confidential
2-52
Matching of color parameter fails.
User Check
- Turn the power off and on.
Level of second side CIS scan result is detected as abnormal during FAX transmission
(first transmission.)
Error Code A8
Unable to Scan A8
LCD
Step Cause Solution
1 Program malfunctioning Re-load the firmware.
2 Main PCB defective Replace the main PCB ASSY.
Error Code AC
Unable to Scan AC
LCD
Step Cause Solution
1 White level data failure Carry out maintenance 55 to obtain white label
data.
2 White reference film stained Clean the white reference film of document
pressure bar of the document scanner unit.
3 Second side CIS unit defective Replace the second side CIS unit.
4 White reference film damaged,
broken
Replace the document scanner unit.
5 Main PCB defective Replace the main PCB ASSY.
