Brother MFC-J2320 Service Manual

Confidential
2-6
2.3 Parts Names and Functions
 Document scanning and feeding
Parts Names Functions
Document detection actuator This detects whether documents are set on the document tray.
Document pick-up roller
This pulls documents loaded in the document tray into the ADF.
Document separation roller,
ADF separation pad
This separates documents sent by the document pick-up roller
in single sheet.
Document feed roller This feeds a document to the CIS unit.
Second side document
scanning position actuator
This detects the leading edge and the ending edge of the
document, adjusting the scanning position on the second side.
This detects paper jamming in the ADF.
First side document
scanning position actuator
This detects the leading edge and the ending edge of the
document, adjusting the scanning position on the first side.
This detects paper jamming in the ADF.
Document ejection roller This ejects the scanned document to the document ejection
tray.

Brother MFC-J2320 Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi
Max Print Resolution	6000 x 1200 dpi
Max Print Size	A3
Scanner Type	Flatbed with ADF
Max Scan Resolution	1200 x 2400 dpi
Copy Speed (Black)	12 cpm
Copy Speed (Color)	9 cpm
Paper Tray Capacity	250 sheets
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Display	2.7" LCD touchscreen
Paper Handling	A3, A4
