Brother MFC-J2320 Service Manual

Confidential
2-41
Head/carriage unit cannot shift to head capping position.
Head/carriage unit cannot shift to head uncapping position.
Head property information not input.

Error Code 75
Unable to Print 75
LCD
Error Code 76
Unable to Print 76
LCD
Step Cause Solution
1 CR encoder strip out of place Set the CR encoder strip into place.
2 Foreign materials in the
maintenance unit
Remove foreign materials.
3 Foreign materials in the engine
unit
Remove foreign materials.
4 Carriage motor defective Replace the carriage motor ASSY.
5 Switching lever guide defective
Maintenance unit defective
Replace the maintenance unit.
6 Main PCB defective Replace the main PCB ASSY.

Error Code 7E
MACHINE ERROR 7E
LCD
Step Cause Solution
1 Head property information not
input
Input the head property information (refer to
Chapter 5, Section 1.3.25.)
2 Main PCB defective Replace the main PCB ASSY.

Brother MFC-J2320 Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi
Max Print Resolution	6000 x 1200 dpi
Max Print Size	A3
Scanner Type	Flatbed with ADF
Max Scan Resolution	1200 x 2400 dpi
Copy Speed (Black)	12 cpm
Copy Speed (Color)	9 cpm
Paper Tray Capacity	250 sheets
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Display	2.7" LCD touchscreen
Paper Handling	A3, A4
