Brother MFC-J2320 Service Manual

Confidential
2-26
Black ink cartridge reaches service life time.
After judging as no ink by the ink remaining sensor, ink discharged for specified times.
Yellow ink cartridge reaches service life time.
After judging as no ink by the ink remaining sensor, ink discharged for specified times.
Cyan ink cartridge reaches service life time.
After judging as no ink by the ink remaining sensor, ink discharged for specified times.
Magenta ink cartridge reaches service life time.
After judging as no ink by the ink remaining sensor, ink discharged for specified times.
User Check
- Replace the ink cartridge.

Error Code 26
B&W 1-sided Print Only/Cannot Print Replace Ink
Cannot detect ink volume
LCD
Error Code 27
B&W 1-sided Print Only/Cannot Print Replace Ink
Cannot detect ink volume
LCD
Error Code 28
B&W 1-sided Print Only/Cannot Print Replace Ink
Cannot detect ink volume
LCD
Error Code 29
B&W 1-sided Print Only/Cannot Print Replace Ink
Cannot detect ink volume
LCD
Step Cause Solution
1 Ink remaining sensor defective Replace the ink refill ASSY.
2 Main PCB defective Replace the main PCB ASSY.

Brother MFC-J2320 Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi
Max Print Resolution	6000 x 1200 dpi
Max Print Size	A3
Scanner Type	Flatbed with ADF
Max Scan Resolution	1200 x 2400 dpi
Copy Speed (Black)	12 cpm
Copy Speed (Color)	9 cpm
Paper Tray Capacity	250 sheets
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Display	2.7" LCD touchscreen
Paper Handling	A3, A4
