Brother MFC-J2320

3-53
Confidential
Assembling Note: Assemble new First side CIS flat cable and FFC tension film as
shown below.
Fig. 3-44
Folding instructions
890
Double-sided tape
(to be attached onto the back)
(Unit: mm)
320222246.5
47
116.5
83.5
45°
45°
45°
45°
14
14
To CIS unit
To main body
UL symbol
print side
Mountain fold
Valley fold
Double-sided tape attachment position
To
CIS unit
To main body
UL symbol
print side
47
13.5
FFC tension film
Double-sided tape
(to be attached onto the back)
Hook two
pawls here.
13.5
0-2
1
1.5 1.5
14
14
320
542
