Brother MFC-J2320

3-89
Confidential
(3) Remove the two CR frame springs and two screws (TAPTITE CUP B M3x10) and
remove the CR frame.
Fig. 3-96
(4) Remove the Flushing base.
Fig. 3-97
CR frame
CR frame spring
CR frame spring
TAPTITE CUP B M3x10
Flushing base
