Brother MFC-J2320 Service Manual

5-61
Confidential
1 Real-time clock (RTC) check result *1 21
Ink drop count by cleaning at the previous
replacement of ink cartridge
2
RTC backup check result *1
OK: Backup completed, NG: Backup failed
22 Ink drop count at ink remaining failure
3 Model code 23
Total paper pull-in failure count
("No Paper Fed" count)
4 Country code 24
Total printed page count/Total printed page
count in the previous month/Printed
recording paper jam count
5
Checksum of WSW, PSW, USW, and FSW
*1
25
High-level ink usage page count (count of
pages that exceed a specified level of ink
usage)
6 Version of main firmware 26
Printed page count for all paper sizes/
Printed page count for A3 and ledger/
Printed page count for other sizes
7 Version of boot firmware *1 27 Printed page count by printing method
8 Serial number 28
Printed page count by paper size and by
paper type in duplex printing *2
9
Head property information/Head voltage
correction value/Head calibration data –
calibration ratio – Presence of variation
calibration data
29
Total printed page count in duplex printing/
Jam count in duplex printing
10
First side CIS type/Second side CIS type/
Engine type/LCD type
30
Page count in duplex printing by printing
method
11 PictBridge information *1 31
Printed page count by paper size and by
paper type in duplex printing *2
12
Ink drop count after replacement of ink
cartridge
32
Tray 1 total printed page count/Tray 1 jam
count/Tray 2 total printed page count/Tray 2
jam count
13 Ink drop count after detection of "Ink Low" 33
Total printed label count *3/Label jam count *3/
Total print count in printing via manual feed
slot/Manual feed slot jam count/MP tray total
printed page count/MP tray jam count
14
Ink drop count for droplets jetted out onto
the platen *1
34
Roller cleaning count (Tray 1/Tray 2/MP
tray) *3
15
Total ink drop count from a new head
(including flushing)
35 Paper piece removal count *3
16 Ink drop count by cleaning from ink renewal 36
ADF scanning count/ADF duplex scanning
count *3/FB scanning count/ADF jam count/
FAX scanning count/Scanner count
17
Ink cartridge change count (High-yield and
super high-yield ink cartridges)
37
Home positioning error code of the CIS unit/
Home positioning detection log data *1
18
Ink cartridge detection failure count (Cannot
Detect display count)
38
Purge count/Sensor purge count *3/Wipe
count/Black flushing count/Color flushing
count/Flushing count error detection count
19
Ink drop count at the previous replacement
of ink cartridge
39 Purge count (black) *4
20
Ink drop count after detection of "Ink Low"
at the previous replacement of ink cartridge
40 Purge count (color) *4
