Brother MFC-J6535DW Service Manual

1-3
Confidential
*1
Only for US area
Model MFC-J6545DW MFC-J6730DW MFC-J6930DW MFC-J6935DW
Media
Sizes
Standard Tray
<Landscape> A4, LTR, EXE
<Portrait> A3, LGR, LGL, Folio, A5, A6, Photo (102 x 152 mm/4 x 6"),
Index card (127 x 203 mm/5 x 8"), Photo-L (89 x 127 mm/3.5 x 5"), Photo-2L (127 x 178 mm/5 x
7"), C5, Com-10, DL Envelope, Monarch, Mexico Legal, India Legal
Lower Tray
N/A
<Landscape> A4, LTR
<Portrait> A3, LGR, LGL, Folio, Mexico Legal, India Legal
3rd Tray
N/A
Manual Feed Slot
N/A
<Landscape> A4,
LTR, EXE,
<Portrait> A3, LGR,
LGL, Folio, A5, A6,
Photo (102 x 152 mm/
4 x 6"), Index card
(127 x 203 mm/5 x 8"),
Photo-L (89 x 127 mm/
3.5 x 5"), Photo-2L
(127 x 178 mm/5 x 7"),
C5, Com-10, DL
Envelope, Monarch,
Mexico Legal, India
Legal
N/A
MP Tray
<Landscape> A4,
LTR, EXE
<Portrait> A3, LGR,
LGL, Folio, A5, A6,
Photo (102 x 152 mm/
4 x 6"), Index card
(127 x 203 mm/5 x 8"),
Photo-L (89 x 127 mm/
3.5 x 5"), Photo-2L
(127 x 178 mm/5 x 7"),
Com-10, DL Envelope,
Monarch, C5, Mexico
Legal, India Legal
N/A
<Landscape> A4, LTR, EXE
<Portrait> A3, LGR, LGL, Folio, A5, A6, Photo
(102 x 152 mm/4 x 6"), Index card (127 x 203
mm/5 x 8"), Photo-L (89 x 127 mm/3.5 x 5"),
Photo-2L (127 x 178 mm/5 x 7"), Com-10, DL
Envelope, Monarch, C5, Mexico Legal, India
Legal
Duplex Print
<PC Print> A3, LGR, LGL, Folio, A4, LTR, EXE, A5, Mexico Legal, India Legal
<Copy> A3, LGR, LGL, Folio, A4, LTR, EXE
*1
, A5, Mexico Legal, India Legal
ADF (width/length) 105/148 mm to 297/431.8 mm (4.1/5.8" to 11.7/17.0")
Scanner Glass
(width/length)
up to 297/431.8 mm (up to 11.7/17.0")
