Brother MFC-J6535DW Service Manual

3-50
Confidential
9.6 Jam Clear Cover
(1) Open the Jam clear cover.
(2) Release the two Pins and remove the Jam clear cover from the Main body.
Note: When replacing the Jam clear cover, be sure to remove the serial number label
attached on the old cover and attach it to the new cover.
Fig. 3-30
Main body
Pins
Jam clear cover
