Confidential

2-50

■ Error Code 9F00

3rd tray paper feed motor cannot stop.

Error Code 9F01

3rd tray paper feed motor encoder sensor cannot detect rotation of the 3rd tray

paper feed motor.

■ Error Code A000

Time out occurred during data transfer for second side document scanning.

■ Error Code A100

Document scanner sensor detects that document scanner is open.

< User Check >

- Close the document scanner.

Step Cause Solution

1 3rd tray paper feed motor

harness connection failure

Reconnect the 3rd tray paper feed motor

harness.

2 3rd tray paper feed motor

defective

Replace the 3rd tray paper feed motor.

3 3rd tray relay PCB defective Replace the 3rd tray relay PCB.

4 Main PCB defective Replace the main PCB.

Step Cause Solution

1 Second side CIS flat cable

connection failure

Reconnect the second side CIS flat cable.

2 Second side CIS unit defective Replace the second side CIS unit.

3 Main PCB defective Replace the main PCB.

Step Cause Solution

1 Document scanner sensor

harness connection failure

Reconnect the document scanner sensor

harness.

2 Document scanner unit boss

broken

Replace the document scanner unit.

3 Main PCB defective Replace the main PCB.
