Brother MFC-J6535DW Service Manual

3-7
Confidential
5 LUBRICATION
Lubricant type
(manufacturer)
Lubrication points Lubricant amount
FLOIL BG-14NSU
(Kanto Kasei)
Head/carriage unit 2 1.0 mm diameter ball
Permalub BAN-5
(Nippeco)
1 1.5 mm diameter ball
FLOIL BG-14NSU
(Kanto Kasei)
CR guide rail and CR frame (top face) 56 2.0 mm diameter ball
CR frame
(inner side of the rear upright edge
and inner side of the front upright
edge)
66 2.0 mm diameter ball
CR frame (bottom face) 2 1.0 mm diameter ball
FLOIL BG-10KS
(Kanto Kasei)
Paper ejection roller 4 1.0 mm diameter ball
Permalub BAN-5
(Nippeco)
Paper feed roller 2 x Twice 2.0 mm diameter ball
1 1.0 mm diameter ball
FLOIL BG-10KS
(Kanto Kasei)
Paper pull-in roller holder 2 2.0 mm diameter ball
Platen 6 1.0 mm diameter ball
3rd tray sensor holder 7 2.0 mm diameter ball
Permalub BAN-5
(Nippeco)
Intermediate roller bushing 1 2.0 mm diameter ball
FLOIL BG-10KS
(Kanto Kasei)
< India model only >
Paper tray ASSY #1
4 1.5 mm diameter ball
< India model only >
Output paper tray
4
1.5 mm diameter ball
< India model only >
ADF document support
11.5 ～ 2.0 mm diameter
ball
