Location of screw Screw type Q’ty
Tightening
N•m (kgf•cm)
Paper feed motor plate SCREW PAN (S/P
WASHER) M3x6
1 0.30±0.10 (3±1)
SCREW PAN (S/P
WASHER) M3x6
(Screws to be tightened after
the PF roller belt is
mounted.)
1 0.60±0.10 (6±1)
Frame base ASSY TAPTITE CUP B M3x10 4 0.35±0.05 (3.5±0.5)
Flushing box TAPTITE CUP B M3x10 2 0.35±0.05 (3.5±0.5)
Paper feed arm frame ASSY TAPTITE CUP B M3x10 2 0.35±0.05 (3.5±0.5)
Tray FG wire TAPTITE CUP B M3x10 1 0.35±0.05 (3.5±0.5)
Lower cover frame TAPTITE CUP B M3x10 3 0.35±0.05 (3.5±0.5)
3rd tray unit TAPTITE BIND B M4x12 6 0.70±0.10 (7±1)
3rd tray relay PCB TAPTITE CUP B M3x10 2 0.50±0.05 (5±0.5)
3rd tray sensor holder ASSY SCREW PAN (S/P
WASHER) M3x6
2 0.65±0.05 (6.5±0.5)
3rd tray earth frame B SCREW CUP M3x6 1 0.65±0.05 (6.5±0.5)
3rd pressure roller ASSY SCREW CUP M3x6 1 0.65±0.05 (6.5±0.5)
3rd tray earth frame A TAPTITE CUP B M3x10 1 0.50±0.05 (5±0.5)
3rd tray frame ASSY TAPTITE CUP B M3x10 1 0.50±0.05 (5±0.5)
3rd tray idle gear frame TAPTITE CUP B M3x10 2 0.50±0.05 (5±0.5)
SCREW CUP M3x6 1 0.65±0.05 (6.5±0.5)
3rd tray motor frame SCREW CUP M3x6 2 0.65±0.05 (6.5±0.5)
3rd tray paper feed motor SCREW BIND M3x6 2 0.65±0.05 (6.5±0.5)
3rd lower cover frame TAPTITE CUP B M3x10 4 0.50±0.05 (5±0.5)
