Brother MFC-J6535DW Service Manual

3-5
Confidential
Location of screw Screw type Q’ty
Tightening
N•m (kgf•cm)
Ink ABS upper box ASSY TAPTITE CUP B M3x10 2 0.35±0.05 (3.5±0.5)
Main PCB earth frame SCREW CUP M3x6 2 0.35±0.05 (3.5±0.5)
Main PCB earth frame R SCREW CUP M3x6 2 0.35±0.05 (3.5±0.5)
Modem PCB frame TAPTITE CUP B M3x10 2 0.35±0.05 (3.5±0.5)
Main PCB earth frame R2 SCREW CUP M3x6 1 0.40±0.10 (4±1)
T2 FG wire SCREW BIND M3x6 1 0.35±0.05 (3.5±0.5)
PF FG wire
Engine FG wire SCREW BIND M3x6 1 0.35±0.05 (3.5±0.5)
Main PCB frame TAPTITE CUP B M3x10 1 0.35±0.05 (3.5±0.5)
SCREW CUP M3x6 1 0.35±0.05 (3.5±0.5)
CR frame ASSY TAPTITE CUP B M3x10 2 0.55±0.05 (5.5±0.5)
CR guide rail TAPTITE CUP B M3x10 2 0.55±0.05 (5.5±0.5)
Maintenance unit
< Made-in-China machine >
TAPTITE CUP B M3x10
1 0.35±0.05 (3.5±0.5)
< Made-in-Philippines
machine >
TAPTITE BIND B M4x12
1 0.70±0.10 (7±1)
SCREW BIND M3x6 2 0.60±0.10 (6±1)
Paper feed arm frame ASSY SCREW BIND M3x10 1 0.5±0.1 (5±1)
TAPTITE CUP B M3x10 1 0.5±0.1 (5±1)
Lower tray unit TAPTITE BIND B M4x12 1 0.70±0.10 (7±1)
Tank case support TAPTITE CUP B M3x10 1 0.35±0.05 (3.5±0.5)
Ink refill ASSY TAPTITE CUP B M3x10 2 0.35±0.05 (3.5±0.5)
Ink absorber box (with Lower tray)
TAPTITE CUP B M3x10
2 0.50±0.05 (5±0.5)
Ink absorber box (without Lower tray) 4 0.35±0.05 (3.5±0.5)
CR frame ASSY TAPTITE CUP B M3x10 1 0.55±0.05 (5.5±0.5)
TAPTITE CUP S M3x6 1 0.65±0.1 (6.5±1)
Motor plate SCREW BIND M3x6 2 0.75±0.10 (7.5±1)
Carriage motor SCREW BIND M3x6 2 0.75±0.10 (7.5±1)
Lower tray unit TAPTITE BIND B M4x12 3 0.70±0.10 (7±1)
LT frame ASSY TAPTITE CUP B M3x10 3 0.50±0.05 (5±0.5)
Idle gear holder frame LT ASSY SCREW CUP M3x6 1 0.60±0.10 (6±1)
Bank chute LT TAPTITE BIND B M3x10 2 0.50±0.05 (5±0.5)
Power supply unit TAPTITE CUP B M3x10 1 0.35±0.05 (3.5±0.5)
Power supply PCB ASSY SCREW CUP M3x6 3 0.40±0.10 (4±1)
AC cord FG wire
SCREW PAN (S/P
WASHER) M3.5x6
1 0.45±0.05 (4.5±0.5)
Switchback frame ASSY TAPTITE CUP B M3x10 2 0.35±0.05 (3.5±0.5)
SCREW BIND M3x6 2 0.70±0.10 (7±1)
Encoder cover SCREW BIND M3x6 2 0.60±0.10 (6±1)
Encoder sensor holder SCREW BIND M2x12 2 0.15±0.05 (1.5±0.5)
CR guide rail SCREW BIND M3x6 2 0.65±0.05 (6.5±0.5)
