*7: Noted in the following order: previous purge (black, color), purge prior to that (black, color),
and purge prior to that (black, color). Each 4-digit value is noted in hexadecimal notation.
Convert each to a 16-digit binary value and consult the table below ("How to read the purge
logs") for its meaning. Each 16-digit value consists of the following components:
< How to read the purge logs >
< Regular Ink cartridge model > < Ink tank model / Simple Ink cartridge model >
- First 2 digits: Purge execution trigger - First 2 digits: Not used
- Next 6 digits: Purge execution type - Next 6 digits: Purge execution type
- Next 4 digits: Cause of purge execution - Next 4 digits: Cause of purge execution
- Last 4 digits: Not required for servicing - Next 4 digits: Purge execution trigger
Purge execution
trigger
(Regular Ink cartridge
model)
Purge execution type Cause of purge execution Purge execution trigger
(Ink tank model / Simple Ink
cartridge model)
00 User-execution 000000 No purge execution 0000 None (user-execution) 0000 None applies
01 Before printing 000001 NP 0001 Initial installation 0001 Selection from test
print
10 Automatically
executed
000010 RP 0010 Periodic purge
000011 PP 0011 Ink replacement 0010 Selection from User
mode
000100 CP 0100 12th ink replacement
000101 uIP 0101 Purge to eliminate paper
dust
0011 Selection from
Maintenance mode
of machine
000110 MPP
000111 TPP (Regular Ink
cartridge model)
QAP ((Ink tank model/
Simple Ink cartridge
model)
0110 30th power ON/OFF
0111 Machine error/power off 0100 Selection from
Maintenance tab on
PC
1000 M-misdirection purge
1001 Purge before printing
after dry
0101 Before printing
001000 Suction without ink 1010 Low PV user purge 0110 Periodic purge,
HBP purge
001001 SPP 1011 20th purge for ME5X7X
001010 MNT Initialization 1100 No PV user purge before
printing
001011 WIPE
001100 REM
001101 Suction without ink
001110 Periodic flush
001111 MPP2
010000 QMPP
010001 Flush to retain
moisture
010010 HPP
010011 Reset exhaustion
010100 eIP
010101 RP3
010110 ARP
010111 QPP
011000 Continuous
exhaustion
011001 CPP
011010 UncapCap
011011 Wait
011100 SP
011101 RP2
011110 SRP
100000 REP
100100 Air cleaning
100101 Black sedimentation
suction purge
100110 LRP
