1 - 6
Outline of Mechanism Positions of electronic components
ASSY: Power PCB 100
(ASSY: Power PCB 200)
ASSY: Power SW
ASSY: USB PCB
ASSY: TH cutter motor
ASSY: TH cutter sensor
ASSY: Y area sensor
ASSY: Picker motor
ASSY: Picker sensor
ASSY: X motor
ASSY: Connect PCB
ASSY: Y motor
ASSY: Hoop sensor
ASSY: Hoop PCB
ASSY: X area sensor
ASSY: TH motor
ASSY: Needle TH sensor
ASSY: Wiper sensor
ASSY: Wiper motor
ASSY:Index sensor
ASSY: Color change sensor
ASSY: Index motor
ASSY: Main motor
