Brother PR600 - Positions of Electronic Components

1 - 5
Outline of
Mechanism
Outline of Mechanism Positions of electronic components
ASSY: TH sensor
ASSY: Head PCB
ASSY: FD PCB
ASSY: Inverter PCB
(INVERTER:IM4302)
ASSY: SW PCB
Touch panel
(TOUCH PANEL:EMU601A2B040)
LCD module
(LCDM:LM8M64)
ASSY: Panel PCB
FD drive
(FDD:FD-05HG-5661)
ASSY: Main PCB
ASSY: Main shaft sensor
