SERVICE SPECIFICATIONS AND SPECIAL TOOLS
STANDARD TORQUE SPECIFICATIONS
STANDARD TORQUE SPECIFICATIONS
Standard Torque Chart
Size In. Lbs. Ft. Lbs. N·m
No. 6 7–10 0.58–0.83 0.8–1.1
No. 8 15–22 1.25–1.83 1.7–2.5
No. 10 24–36 2–3 2.7–4.0
No. 12 36–48 3–4 4.0–5.4
1/4 in. 60–84 5–7 6.7-9.4
5/16 in. 120–144 10–12 13.5–16.2
3/8 in. 216–240 18–20 24.4–27.1
7/16 in. 336–384 28–32 37.9–43.4
IMPORTANT: These values apply only when a specific
torque for a specific fastener is not listed in the appropri-
ate section. When tightening two or more screws on the
same part, DO NOT tighten screws completely, one at a
time.
WARNING
Torque wrench tightening specifications
must be strictly adhered to. Replace any
locking fastener (locknut or patch screw)
if its locking feature becomes weak. Defi-
nite resistance to turning must be felt
when reusing a locking fastener.
If replacement is specified or required
because the locking fastener has become
weak, use only authorized Evinrude/
Johnson Genuine Parts.
