243
POWERHEAD
DISASSEMBLY
10
Carefully remove the crankcase from the cylinder
block to avoid damaging the crankshaft seal rings.
Cylinder Head
Loosen in stages and remove cylinder head
retaining screws. Remove the cylinder heads. Dis-
card thermostat seals.
Connecting Rods and Pistons
Use a permanent marker to identify each connect-
ing rod cap, connecting rod, and piston by cylinder
number. Number 1 is closest to the flywheel.
Use Torquing Socket, P/N 331638, to loosen in
stages the rod cap retaining screws. DO NOT
remove the screws.
005304
1. Cylinder head screws (28 on V4; 40 on V6) 005302
11
005292
005303
