390
TRIM AND TILT
ADJUSTMENTS
Fill the oil reservoir up to the fill plug with
Evinrude/Johnson Biodegradable TNT Fluid.
Install and tighten the fill plug. Do not torque the
plug at this time.
Run the motor, then recheck oil level. Cycle the
unit several times and check the oil level when the
cylinder is fully extended. Oil should be level with
bottom of fill port. Install and tighten the fill plug to
a torque of 45 to 55 in. lbs. (5 to 6 N·m).
ADJUSTMENTS
Refer to Trim Sending Unit Adjustment on
p. 76.
Refer to Tilt Limit Switch Adjustment on p. 75.
1. Reservoir cap 004278
1
