245
POWERHEAD
DISASSEMBLY
10
Crankshaft
Carefully lift crankshaft straight up and remove
from crankcase.
Remove upper seal from crankshaft. Discard the
seal. A new upper seal must be installed on
assembly.
If the lower crankshaft is to be resealed or the
lower bearing replaced, remove the lower bearing
seal housing.
Remove the housing O-ring. Discard O-ring.
To remove the housing seal, use a punch as
shown. Discard seal.
Inspect housing and replace if necessary.
WARNING
Wear safety glasses to avoid injury.
005285
49068
005280
002044
1. Punch 002053
1
