MLD Querier
If MLD querier is enabled, MLD snooping can be enabled even if no multicast router is connected.
MLD Querier Check to enable MLD querier. MLD queries will be forwarded from each VLAN.
Querier Interval
Configure the transmit interval for the querier that confirms the existence of
multicast group’s member.
Querier Source IPv6
Address
Enter the source IPv6 address of the querier.
Max Response Time
Configure the time between transmitting the querier and response from
the member. If the member responds to the querier by this time, the querier
determines that the member is connected.
MLD Router Port
Specify the port connected to the multicast router (server) for each VLAN.
MLD Router Port Settings
Enter the VLAN ID and specify the port connected to the multicast router (server),
then click [Add].
