CAB SQUIX Configuration Manual

22 22
6.1.12 Display
 Start menu.
 Select Setup > Display.
Parameter Meaning Default
Orientation
Adaptation of the display contents to the display orientation.
0°
Brightness
Brightness of the LCD display.
8
Time powersave
Time between the last operation and activation of energy-saving mode.
5 min
Table 20 Parameters of the Setup > Display menu
6.1.13 Interpreter
 Start menu.
 Select Setup > Interpreter.
Parameter Meaning Default
Character set
Selection of the character set table for adaptation to the computer
system used. Switching the character set via software is not possible.
Characters not available in the selected character set can be accessed
using the Unicode table.
UTF-8
USB
Choosing between the programming languages JScript and ZPL for data
transfer via USB interface
JScript
RS-232
Choosing between the programming languages JScript and ZPL for data
transfer via RS-232 interface
JScript
FTP
Choosing between the programming languages JScript and ZPL for data
transfer via FTP
JScript
LPD
Choosing between the programming languages JScript and ZPL for
printing with LPD
JScript
RawIP
Choosing between the programming languages JScript and ZPL for
printing with RawIP
JScript
Bluetooth
Choosing between the programming languages JScript and ZPL for
data transfer via Bluetooth
 only with Bluetooth adapter installed
JScript
Table 21 Parameters of the Setup > Interpreter menu
6.1.14 ZPL
 Start menu.
 Select Setup > ZPL.
Parameter Meaning Default
> Printing width
Setting the print width for ZPL programming
100.0 mm
> Label length
Setting the label length for ZPL programming
150.0 mm
Table 22 Parameters of the Setup > ZPL menu
6 Conguration

CAB SQUIX Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Print Resolution	300 dpi
Max Print Speed	300 mm/s
Display	LCD
Interfaces	USB, Ethernet, Serial (RS232), USB Host
Memory	64 MB RAM
Media Sensors	Reflective, transmissive
Label Length	5 to 4000 mm
Keyboard	Optional
Supported Materials	Paper, plastic, textile
