CAB SQUIX Configuration Manual

23
6.2 Conguration via the Web Interface
Theparametersaccessibleviathecontrolpanelcanalsobesetviathewebinterfacecontainedinthermwareofthe
printer.
The printer web interface can be accessed with a browser (e.g. Microsoft Internet Explorer, Mozilla Firefox) with
JavaScript activated via the Ethernet interface or the optional WLAN interface.
Calling Up the Web Interface
!
Attention!
Whenever settings are changed via the web interface you are requested to enter the user name "admin"
and a password. The default value of the password is also "admin". The password can be changed via the
web interface ( “Setup Tab” page 26).
 Start the browser.
 Call the web interface by entering the IP address via HTTP (e.g. http://192.168.100.208).
The "Status" tab is open on the home screen.
The web interface contains the following tabs:
• Status: general status description  page 24.
• Setup:congurationparametersettings page 25.
• Security: password settings  page 26.
• Devices: list of the hardware and optional components  page 27.
• Fonts: overview of the available fonts  page 27.
6 Conguration

CAB SQUIX Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Print Resolution	300 dpi
Max Print Speed	300 mm/s
Display	LCD
Interfaces	USB, Ethernet, Serial (RS232), USB Host
Memory	64 MB RAM
Media Sensors	Reflective, transmissive
Label Length	5 to 4000 mm
Keyboard	Optional
Supported Materials	Paper, plastic, textile
