7 Test Functions
7.5 Test Grid
The Test grid function prints out a geometric pattern on a background grid. This allows you to assess the evenness of
the print quality.
TheprintoutoccursusingtheheatlevelandprintspeedspeciedintheSetup > Printing menu.
Notice!
The printout occurs without taking the label gaps into consideration. This is why endless media are most
suitable for this purpose.
Insert printable medium (labels, endless paper) which extends across the entire printing width.
If the printout is to occur using thermal transfer printing, insert transfer ribbon with the maximum width.
Start menu.
Select Test > Test grid.
The geometric pattern is printed every 3 seconds once the Test grid function is started.
The printout can be canceled with
.
Figure 15 Test grid
