CAB SQUIX Configuration Manual

56 56
14 Storage Devices
Label descriptions, graphics, fonts, and database information can be saved for the long-term on memory media.
i
Notice!
 Always create a backup copy of external devices in case of a malfunction.
14.1 Suitable Storage Devices
External Devices
• USBashdriveatUSBmasterinterface.
• SD cards
Internal Device
• approx.50MBashmemoryinsidetheprinter(InternalFlashFileSystemIFFS)
14.2 Installation

For external storage devices only!
 SlideSDcardcontact-siderstintothematchingslotuntilitlatches.
To unlatch SD card press it shortly into the slot and remove it.
or
 ConnectUSBashdrivetoanUSBmasterinterface.
!
Attention!
Risk of data loss !
 Do not remove the storage device while it is being accessed.
14.3 Directory Structure
On storage devices connected to the printer, the following directory structure is automatically generated when
uploadingles:
Folder name Contents
fonts
Fontles
images Graphicles
labels Labeldescriptionles
misc Firmware,PPP,SetupandTMPles
Table 31 Directory structure

CAB SQUIX Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Print Resolution	300 dpi
Max Print Speed	300 mm/s
Display	LCD
Interfaces	USB, Ethernet, Serial (RS232), USB Host
Memory	64 MB RAM
Media Sensors	Reflective, transmissive
Label Length	5 to 4000 mm
Keyboard	Optional
Supported Materials	Paper, plastic, textile
