CAB SQUIX Configuration Manual

37
8 Diagnostic Functions
8.4 Save Data Steam

Access only with external storage device!
The function Save data stream
allowstostoredataincomingviaaninterfaceasan.lblletoanexternalstoragedevice
(SD card, USB memory module) installed on the printer.
 Insert SD card or USB memory module.
 Start menu.
 Select Diagnostics > Save data stream.
 Select the external storage device.
 Enteralename.
Thepredenednameiscomposedoftheidentier"log",date,clocktimeandthesufx".lbl",butmayalsobe
altered.
Conrmtheselectionwith .
 In the status line of the display the data saving is indicated by the symbol .
 Sendprintjobs.Alldatareceivedbytheprinterarestoredinthe.lblle.
 To complete the function select Diagnostics > Save data streamagainandconrmwithOK.The.lbllewillbestoredin
the root of the storage device.
Figure 20 Saved data stream

CAB SQUIX Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Print Resolution	300 dpi
Max Print Speed	300 mm/s
Display	LCD
Interfaces	USB, Ethernet, Serial (RS232), USB Host
Memory	64 MB RAM
Media Sensors	Reflective, transmissive
Label Length	5 to 4000 mm
Keyboard	Optional
Supported Materials	Paper, plastic, textile
