CAB SQUIX Configuration Manual

39
8 Diagnostic Functions
8.6 Save System Log

Access only with external storage device!
The function Save system log
allowstostoreseveralsystemlespackedtoa.zipletoanexternalstoragedevice
(SD card, USB memory module) installed on the printer.
 Insert SD card or USB memory module.
 Start menu.
 Select Diagnostics > Save system log.
 Select the external storage device.
 Enteralename.
Thepredenednameiscomposedoftheidentier"sys",date,clocktimeandthesufx".png",butmayalsobe
altered.
 Conrmtheselectionwith . The display shows the several steps of saving.
Figure 22 System log saving
 Conrmthecompletionofsavingwith .The.ziplewillbestoredintherootofthestoragedevice.

CAB SQUIX Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Print Resolution	300 dpi
Max Print Speed	300 mm/s
Display	LCD
Interfaces	USB, Ethernet, Serial (RS232), USB Host
Memory	64 MB RAM
Media Sensors	Reflective, transmissive
Label Length	5 to 4000 mm
Keyboard	Optional
Supported Materials	Paper, plastic, textile
