Calix E3-48C User Manual

164
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Parameter Description Valid Options
Out Of Band DTMF Out-of-band Dual-Tone Multi-Frequency (DTMF) mode.
 Select Info to relay DTMF tones as SIP INFO
messages.
 Select rfc2833 to relay DTMF tones according to RFC
2833. (Only supported on GigaCenter ONTs.)
 Select none to not relay DTMF tones.
none ‡, rfc2833, info
Local Hook Flash Defines where hook-flash control resides.
 When enabled (selected), the local User Agent will
consume the hook-flash and provide the service
locally.
 When disabled (unselected), then the hook-flash is
passed to the Softswitch for processing.
selected (enabled) ‡,
unselected (disabled)
RTP DSCP The DiffServ Code Point (DSCP) value for traffic using
this SIP profile.
 0-63 - DSCP for RTP packets
 cs0 - DSCP CS0 (0)
 cs1 - DSCP CS1 (8)
 af11 - DSCP AF11 (10)
 af12 - DSCP AF12 (12)
 af13 - DSCP AF13 (14)
 cs2 - DSCP CS2 (16)
 af21 - DSCP AF21 (18)
 af22 - DSCP AF22 (20)
 af23 - DSCP AF23 (22)
 cs3 - DSCP CS3 (24)
 af31 - DSCP AF31 (26)
 af32 - DSCP AF32 (28)
 af33 - DSCP AF32 (30)
 cs4 - DSCP CS4 (32)
 af41 - DSCP AF41 (34)
 af42 - DSCP AF41 (36)
 af43 - DSCP AF43 (38)
 cs5 - DSCP CS5 (40)
 ef - DSCP EF (46) ‡
 cs6 - DSCP CS6 (48)
 cs7 - DSCP CS7 (56)
RTP Ethernet QoS Ethernet QoS for RTP packets override. 0-7
6 ‡
