165
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Parameter Description Valid Options
Domain Allows you to specify an internet type domain address.
Alternatively, "none" can be used for no domain name.
If present, the domain is used to populate the SIP
destination addresses; the “to” and “request uri” fields. To
use IP in SIP request, set and IP address.
If not present, the proxy server IP is used in these fields.
Example:
Domain: “empty”
Proxy-server: 10.0.20.10
Generated by software:
SIP to: sip:7663339@10.0.20.10
SIP request URI: sip:7663339@10.0.20.10:5060
Example:
Domain: mytelco.com
Proxy-server: 10.0.20.10
Generated by software:
SIP to: sip:7663339@mytelco.com
SIP request URI: sip:7663339@mytelco.com:5060
1-63 character text string, none ‡
Country Code E.164 Country code designator (Protocol Country Variant
profile). This attribute specifies the country code where
the service is being deployed. This code selects country
specific tone settings, line interfaces, line levels and line
frequencies. Currently supported values include the
following:
North America: 1 (GPON and xDSL)
Italy: 39 (xDSL only)
Switzerland: 41 (GPON only)
United Kingdom: 44 (GPON only)
Sweden: 46 (GPON only)
Poland: 48 (GPON only)
Brazil: 55 (GPON only)
Australia: 61 (GPON only)
New Zealand: 64 (GPON only)
Ukraine: 380 (GPON only)
ETSI: 9000 (GPON only)
Note: All ONTs using this profile will reset if country-code
is modified.
Note: Country codes are not currently supported on T-
series ONTs or P-series 700GX ONTs.
1‡ -9999
Release Timer (s) Specifies the amount of time it takes to terminate a call
after an on-hook is detected.
RTP Port Identifies the starting RTP Port range for the SIP RTP
