Section 4. Setting up Datalogger Networks
4.3.7 The Station Summary
The station summary is a view that displays details about the station that is
currently selected on the drawing canvas. By default, it is shown in the lower
right-corner of the Network Planner window. This view provides the following
features:
• An Edit Station Properties link that, if clicked, will present you with a
dialog that contains property sheets for all of the devices and/or links in
the station.
• A list of links to the parts of the report that describe the each of the devices
in the station.
• A description of each device in the station. This description includes the
following:
• The same image that is used as an icon for the device.
• The “official” description of the device.
• A link to edit the properties for the device.
• A link to delete the device (does not appear for the station root device)
4-71
