Section 5. Real-Time Tools
5.1.7.2.1 Adding and Removing Values
The Numeric Display is initially blank when opened; the fields to be displayed
must be selected. Press the Add button to bring up the Add Selection dialog
box that lists the data fields for the available datalogger tables or final storage
arrays.
Table-based dataloggers – If the Add Selection dialog box is
empty, return to the Setup Screen’s Data Files table and select
Get Table Definitions.
NOTES
Mixed-array dataloggers ─ If no array IDs are listed and the
input locations are listed as InputLocation_# instead of with
labels, return to the Setup Screen’s Program tab and associate a
DLD file with the datalogger.
5-15
