Section 4. Setting up Datalogger Networks
Set Station Clock – Press this button to manually set the clock to that of the
LoggerNet server.
The Allowed Clock Deviation setting will prevent a manual
clock set from being carried out if the difference between the
datalogger’s and server’s clocks is less than the specified
deviation.
NOTE
4.2.4.4.6 Program Tab
The program tab displays the name of the program currently running in the
datalogger, if it is known by the LoggerNet server. Table-based dataloggers
store program information in the table definitions. If the table definitions have
been retrieved from the datalogger, LoggerNet should know the name of the
running program. However, mixed-array dataloggers do not store the program
name internally. LoggerNet is made aware of the program name and output
table information when a new program is sent, or when a DLD file that
contains this information is associated with the datalogger. To send a new
program to the datalogger, press the Send button. To associate a program
name with the datalogger, press the Associate button. See Section 5.1.6,
Program Association, for more information.
4.2.4.4.7 File Retrieval Tab (CR1000, CR3000, CR800 Series, and Edlog Dataloggers with
PakBus Operating Systems)
Retrieval Mode – This option determines the schedule for file retrieval.
Disabled – No files are retrieved.
Follow Scheduled Data Collection – Files will be retrieved on the same
schedule that has been set up for scheduled data collection on the
Schedule tab.
New Schedule – Files will be retrieved based on the Base Date and Time
and Collection Interval defined below.
Base Date/Time – Enter a date and a time that the first file retrieval attempt for
the device should occur. If the date and time reflected by these fields has
already passed, retrieval will be attempted immediately when the schedule is
enabled.
Retrieval Interval – Enter the interval on which files should be retrieved from
the device. The retrieval interval is relative to the Base Date and Time entries.
For instance, if the Base Time is set at 12:15 and the interval is set for 1 hour,
file retrieval will be attempted at 12:15, 1:15, 2:15, etc. The format for this
field is 00 d(ays) 00 h(ours) 00 m(inutes) 00 s(econds) 00 m(illi)s(econds).
Delete Files After Retrieval – When this box is selected, the files will be
deleted from the datalogger after they are retrieved.
Add New – When this button is pressed, a new pattern is added to the list of
files to be retrieved. The user must then designate the File Pattern, Output
Directory, Max Files, Force Retrieval, and Record If Skipped fields for this
pattern.
4-22
