Section 8. Working with Data Files on the PC
Zoom Feature
You can zoom in on a particular area of a graph by holding the left mouse
button and dragging the mouse cursor from top-left to bottom-right over the
area to be zoomed. Dragging the mouse cursor from bottom-right to top-left
will undo the zoom. This can also be accomplished by pressing the Undo
Zoom
button on the toolbar.
For a Rainflow Histogram or for a Histogram or FFT in 3D View, you can also
zoom in and out by using the Page Down and Page Up buttons on your
keyboard.
Rotation
For a Rainflow Histogram or for a Histogram or FFT in 3D View, you can
rotate the graph by using the scroll bars at the bottom and right of the graph.
Keeping Graph on Top
The currently selected graph can be kept in front of the data view window by
selecting View | Keep Graph on Top from the menu or pressing this button
on the main View Pro toolbar .
8-14
