CHAPTER 9 EXTERNAL/AUXILIARY MECHANISM
9-22
■ When setting the printer unit into the
main body, ensure that the ↑↓marks
on the seals located on the front and
rear portions of the main unit rail line
up with the positions of the yellow
rollers located on the front and rear
portions of the left edge of the printer
unit.
Figure 9-511
