COPYRIGHT C 1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
A-1
FIGURE A
ASSEMBLY LOCATION DIAGRAM (1/2)
403
CCD LENS MOUNT ASSEMBLY
401
MIRROR ASSEMBLY 2
300
CASSETTE
950
IMAGE PROCESSOR PCB ASSEMBLY
940
FLASH ROM PCB ASSEMBLY
400
MIRROR ASSEMBLY 1
220
SCANNER DRIVE ASSEMBLY
402
MIRROR ASSEMBLY 4
